Shock Tower RESET Plates [Foxbody Mustang / SN95 / New Edge / others]
Shock Tower RESET Plates [Foxbody Mustang / SN95 / New Edge / others]
Couldn't load pickup availability
Fox platform cars have shock towers, not strut towers in the sense that they do not see the load of the coil-springs. From the factory, the springs are contained within the control arms and the subframe, directly distributing their loads into the front frame rails.
With coilover conversions, the towers see loads they simply weren't designed for.
If you don't feel like trusting 40 year old sheet metal and weak spot welds to handle that task, we've got you covered.
Our weld in plates tie the tower interface into the frame rails, reinforcing the tower as a whole. These parts were CAD designed, based on high resolution scan data of the chassis, so the fitment is outstanding.
There are more cars in the fox platform family than most people are aware of.
Fairmounts, LTDs, Granadas, Capris, Mustangs, Lincoln MkVIIs ... the list goes on.
Over the years, these cars have shared the same underpinnings, but even in cases where stampings were otherwise fairly unchanged, bolt infaces came and went.
Such is especially true for the front shock towers.
Combine the design, age and modifications and a lot of fox platform vehicles these days have been converted to use parts from their brethren, leaving many of them with towers that resemble swiss cheese.
Give your fox a fresh start. Start from a clean canvas.
These plates, once bent and welded in place will cover any hole pattern or patterns that may be currently present in your towers and allow you to either start from scratch, or transfer only the pattern you actually need from below.
Want modern "below the sheet metal" mounted SN95 coilovers in your lincoln?
Foxbody Mustang top hats in your SN95?
What ever combination you may be using, these will give you the real estate to make it work.
The result will be clean looking, structurally sound towers.
No more swiss cheese.
Designed and made in the USA.
Made from precision laser cut steel, 3 mm thickness.
Plates come flat and can easily be bent to fit the chassis during install.
See the recommended pre-bend angle graphic to make your job even easier.
MADE TO ORDER, please allow about 2 weeks for manufacturing.
